Egis Single XD NMEA 2000 Relay, 4-Position DT

Description

The Egis Single XD NMEA 2000 Relay provides high-current remote battery switching with networked control and monitoring. It is designed for marine electrical systems that need a compact 500A switching device that can be operated through NMEA 2000 or conventional discrete inputs while still retaining a local manual override.

The relay is rated for 500A continuous and 1600A cranking current and uses a sealed IP67/IP6K9K enclosure with stainless-steel cable studs and high-temperature materials. Bi-stable solenoid technology reduces off-state current draw, helping preserve battery capacity during long periods of inactivity.

NMEA 2000 integration allows compatible systems to control the relay, monitor switch status, and view battery voltage from networked displays or control interfaces. DIP-switch programming provides installation flexibility, and the manual control knob allows the relay to be forced open or closed locally when service or emergency operation requires it.

The module can be expanded with compatible link and cross-link busbars for larger multi-battery arrangements. For boats that need a rugged high-current battery relay with NMEA 2000 integration and local override capability, the Single XD provides a compact network-ready solution. Look through the rest of our battery switches & isolators.
