Blue Sea 8061 AC 50A Toggle Source Selector Panel

Sale!
Blue Sea 8061 AC 50A Toggle Source Selector Panel

Blue Sea 8061 AC 50A Toggle Source Selector Panel

Original price was: $200.76.Current price is: $150.57.

Category:

Description

The Blue Sea Systems 8061 is a 50A AC toggle source selector, letting a boat switch between two 120V AC sources with a mechanical lockout that prevents both being connected at once. It measures 3.75 inches tall by 5.25 wide and weighs 1.84 pounds.

Two 7242 A-Series white toggle double pole 50A breakers do the selecting. The lockout slide is installed from the factory, so the interlock is not something that depends on being fitted correctly on the bench. Maximum panel amperage is 50 amperes.

Hot, neutral and safety ground buses are installed and the panel arrives fully pre-wired. A red reverse polarity LED and a green 120V AC LED are fitted, circuit label positions are backlit as standard, and ON indicating LEDs are installed in all positions. The 8031 basic AC panel label set with 30 labels is included. Browse our marine electrical panels.
