Southwire Surge Guard 50A 120/240V Hardwire Automatic Transfer Switch• 40450RVC3

Description

Transfers to generator power automatically when energized after 30 second delay (generator mode). When both shore and generator power are available, generator dominates after a 30 second delay. Once generator shuts down, shore power activates after 3 second delay.

• Total Electrical Protection From Faulty Park Power
• Provides Protection Against: Power Surges, Open Ground, Open Neutral, Low 102 Volt And High 132 Volt Voltage, Reverse Polarity, Miswired Pedestal, High And Low Frequency
• Multi-Mode Surge Suppression
• RVC Communications Allows Instant Display Of Voltage, Current, And Fault Conditions On An RVC Compatible Device
• RVC Network Communication Of Both Generator And Shore Power Availability Through Exclusive Shore Power Sensing Technology
• Indicator Lights On Front Of ATS Indicate Presence Of Input Power For L1 And L2
• Optional Remote Power Monitor LCD Display
• Type: Automatic
• Function: Transfer Power Between Shore And RV Generator
• Voltage: 120/ 240 Volt
• Ampere Rating: 50 Amp
• Limited 1 Year Warranty
