Raritan Electrode Pack 12V – 32-5000

Description

Raritan Electrode Pack 12V – 32-5000

Keep your Raritan marine sanitation treatment system operating effectively with the Raritan Electrode Pack 12V (32-5000). This genuine Raritan replacement electrode pack is designed for compatible 12V Lectra/San and Electro Scan marine waste treatment systems, providing the critical electrochemical action required during the onboard waste treatment process.

During a treatment cycle, electrical current passes through conductive salt water across the electrode plates. This process produces hypochlorous acid, which acts as a powerful bactericide and oxidizing agent to support the system’s waste-treatment process.

Designed as an OEM replacement component, the 32-5000 Electrode Pack is an ideal choice when servicing worn or deteriorated electrodes in a compatible Raritan treatment unit. Using the correct 12V replacement helps maintain proper system operation and eliminates the uncertainty associated with adapting non-OEM components.

Key Features

• Genuine Raritan Replacement Part: OEM electrode pack for compatible Raritan marine sanitation treatment systems.
• 12V DC Configuration: Specifically designed for 12-volt treatment units; Raritan identifies 32-5000 as its 12V electrode pack.
• Lectra/San & Electro Scan Application: Replacement electrode pack for compatible Raritan Lectra/San and Electro Scan systems.
• Essential Treatment Component: Energized during the treatment cycle as electrical current passes through conductive salt water.
• Electrochemical Treatment: Helps produce hypochlorous acid at the electrode plates as part of the sanitation treatment process.
• OEM Fit & Function: Designed for direct replacement in applicable Raritan systems.

What’s in the Box

The 32-5000 kit is a comprehensive replacement set that includes:

• Electrode Plates: High-performance plates designed for efficient salt-water electrolysis.

• Sealing Gaskets: Fresh gaskets to ensure a watertight seal when reassembling the treatment tank.

• Hardware: Necessary screws and terminals for secure electrical connections.

• Installation Instructions: A guide for proper alignment and wiring.

Key Features

• Compatibility: Designed specifically for 12V ElectroScan and Lectra/San units manufactured after a certain date (verify your serial number).

• Waste Treatment: Facilitates the electrochemical process that converts saltwater into a powerful bactericide, eliminating the need for holding tanks in many areas.

• Durability: Engineered to withstand the harsh chemical environment inside a marine treatment tank.

Maintenance Tip

If your system frequently displays “Low Current” or “High Salt” errors, it is often a sign that the electrodes are scaled or depleted. Regular cleaning with a muriatic acid solution can extend their life, but they must be replaced once the coating has worn away to maintain treatment efficacy.
