Maretron RIM100 Run Indicator Module – RIM100-01

Description

Maretron Run Indicator Module – RIM100-01

Enhance visibility into the operational status of your vessel’s systems with the Maretron Run Indicator Module (RIM100-01) — a compact, NMEA 2000®-enabled device that detects and reports the on/off/run status of connected equipment directly to your boat’s network. Designed for marine and power systems monitoring, the RIM100 turns simple switch closures into actionable data, so you can see at a glance whether pumps, generators, engines, blowers, or other devices are running.

This module integrates seamlessly with your NMEA 2000® backbone, delivering run/stop information to compatible displays, chartplotters, and monitoring software such as Maretron’s N2KView®. With sealed, marine-grade connectors and rugged construction, the RIM100-01 is built to withstand harsh offshore environments while providing reliable status reporting for critical onboard systems.

Whether you’re monitoring engine start/run state, bilge pump activity, blower status, or any other on/off/run condition, this indicator module gives you network-wide awareness of what’s running — improving safety, troubleshooting, and operational insight.

Key Performance Features

• Six-Channel Monitoring: A single module can track six independent devices simultaneously, giving you a centralized view of your vessel’s active systems.

• AC and DC Compatibility: The RIM100 is highly versatile, capable of monitoring both AC (up to 240V) and DC (up to 32V) circuits. This makes it ideal for checking everything from bilge pumps to air conditioning compressors.

• True Status Feedback: Unlike a switch that only tells you if it’s “on,” the RIM100 monitors the voltage at the load. If a breaker trips or a wire breaks, the RIM100 will report that the device is NOT running, even if the helm switch is in the “on” position.

• Consolidated Data: It broadcasts the status of all six channels over the NMEA 2000 bus, making the info available to Maretron DSM570 displays or remote monitoring software.

• Opto-Isolated Inputs: The inputs are optically isolated from the NMEA 2000 network, protecting your sensitive electronics from high-voltage spikes or electrical noise from motors.

What’s In The Box

The RIM100-01 package includes:

• RIM100 Module: The main bridge unit with an NMEA 2000 Micro-C connector.

• Mounting Hardware: Stainless steel screws for secure installation.

• User Manual: Includes detailed wiring diagrams for connecting various AC and DC loads safely.
