Egis Dual XD Flex 2 Relay-ACR with Knobs

Description

The Egis Dual XD Flex 2 Relay-ACR combines a high-current remote relay and automatic charging relay in one compact module. It is intended for two- or three-battery systems that need both controlled battery switching and automatic charge sharing without the space, wiring, and interconnect hardware required by multiple separate devices.

The sealed IP67/IP6K9K housing uses stainless-steel cable studs, high-temperature electronics, and large mounting holes for demanding marine or mobile installations. Bi-stable solenoid technology reduces off-state current draw while helping shrink the overall footprint compared with conventional multi-relay layouts.

Manual override knobs provide local open and closed control and can be left locked in either position for service or emergency operation. DIP-switch programming allows installers to tailor relay behavior, and the module is designed for compatibility with common legacy relay control wiring. Front-facing LED status indication helps confirm operating state at a glance.

Compatible link and cross-link busbars allow the system to expand into larger battery-management layouts. For vessels that need one remote high-current relay and one automatic charge-sharing function in a compact, rugged package, the Dual XD Flex 2 Relay-ACR provides an efficient integrated solution. Worth comparing against our other battery switches & isolators.
