Blue Sea 8043 AC Main +3 Position Toggle Panel

Description

The Blue Sea Systems 8043 is an AC panel with a main plus 3 positions in white toggle format, measuring 7.5 inches tall by 5.25 wide. Three branch circuits is a small boat’s whole AC system, and this arrives with all of it installed.

Three 7210 A-Series white toggle single pole 15A breakers cover the branches and a 7238 double pole 30A toggle serves as the main. A 9353 AC voltmeter reading 0 to 150 volts sits on the face, so incoming shore voltage is visible before you switch anything on. Four green 120V AC LEDs and one red are installed, the red being reverse polarity indication.

Hot, neutral and safety ground buses are installed with the panel fully pre-wired. Circuit label positions are backlit as standard, no kit required, and ON indicating LEDs sit in all circuit positions. The 8031 basic AC panel label set with 30 labels is included. Nominal voltage is 120V AC. See the rest of our marine electrical panels.
