Blue Sea 7135 25A 187-Series Surface Mount Breaker

Sale!
Blue Sea 7135 25A 187-Series Surface Mount Breaker

Blue Sea 7135 25A 187-Series Surface Mount Breaker

Original price was: $69.56.Current price is: $51.51.

Category:

Description

The Blue Sea Systems 7135 is the 25 amp surface mount breaker in the 187 Series, the smallest rating offered in either mounting style. It suits light accessory circuits where you still want a resettable breaker rather than a fuse.

The blade is thermally responsive bi-metal, rated to 48 volts DC, with interrupt capacity of 5,000 amperes at 12 volts, 3,000 at 24 and 1,500 at 42. Operating range is -25°C to +82°C and the class is Type III, switchable with manual reset and trip free.

Because it mounts on the surface there is no cutout to make and no access needed behind the panel. Single lever operation combines switching with protection, the lever reports trip status by its position, and the recessed mounting holes keep the appearance tidy. Terminals are 5/16 studs, the case is thermoset polyester, and the unit is waterproof and SAE J1171 ignition protected. More options in our marine circuit breakers.
