BatteryLink ACR Automatic Charging Relay

Description

Automatically shares single source of charge with Auxiliary Battery.• 120A continuous rating to support high output alternators• 12V/24V DC auto ranging voltage input• Senses charging on two battery banks• Side and bottom knockouts for cable connections• Clip-on cover insulates terminal connections• Studs accept multiple cable terminals• One-piece stainless flange nuts ensure safe and secure connections• Integrated LED indicates ACR status• Quick connect terminals for ground and optional features• Optional Auxiliary Battery Priority connection shares the alternator charge with the • Auxiliary battery longer when the engine is running to allow the use of auxiliary loads for an extended period of time• Remote LED remotely indicates ACR states – requires optional LEDStuds accept multiple cable terminals. One-piece stainless flange nuts ensure safe and secure connections. Integrated LED indicates ACR status. Quick connect terminals for ground and optional features. Optional Auxiliary Battery Priority connection shares the alternator charge with the. Auxiliary battery longer when the engine is running to allow the use of auxiliary loads for an extended period of time. Remote LED remotely indicates ACR states – requires optional LEDFEATURES• 120A continuous rating to support high output alternators• 12V/24V DC auto ranging voltage input• Senses charging on two battery banks• Side and bottom knockouts for cable connections• Clip-on cover insulates terminal connectionsSPECIFICATIONSUnit Weight: 1.25 lbBrand: MarincoMFG Part No.: 7611-BSS
